Product Summary
The AD8509ARU is a 9-channel LCD reference buffer. It is designed to drive 64 gray scale column drivers. The AD8509ARU has an A/B input to select between two voltages for LCD displays. It drives the resistor ladders of LCD column drivers for gamma correction. The applications of the AD8509ARU include LCD line inversion gamma references
Parametrics
AD8509ARU absolute maximum ratings: (1)Supply Voltage: 7 V; (2)Input Voltage: GND to VS; (3)Storage Temperature Range RU Package: -65℃ to +150℃; (4)Operating Temperature Range: -40℃ to +85℃; (5)Junction Temperature Range RU Package: -65℃ to +150℃; (6)Lead Temperature Range (Soldering, 60 sec): 300℃.
Features
AD8509ARU features: (1)Single-supply operation: 3.3 V to 6.5 V; (2)High output current: 300 mA; (3)Low supply current: 6 mA; (4)Stable with 1000 pF loads; (5)Pin-compatible with LMC6009; (6)Pin-compatible with CL-FP6131; (7)48-lead, Pb-free, TSSOP package.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 AD8509ARU-REEL |
Analog Devices Inc |
IC MUX LCD DVR 9CH 3.3V 48TSSOP |
Data Sheet |
Negotiable |
|
||||||
 |
AD8509ARUZ-REEL |
|
IC MUX LCD DVR 9CH 3.3V 48TSSOP |
Data Sheet |
|
|
||||||
