Product Summary
The BCM5646B0KPBG is an integrated multi layer switch.
Features
BCM5646B0KPBG features: (1)24 10/100 Mb and 2 10/100/1000 Mb Ethernet ports; (2)High-speed 2.5-Gbps TurboGigTM stacking link; (3)8.9Mpps (line rate) switching; (4)1-4 Classes of Service (COS); map to 802.1p priority; (5)IGMP snooping; (6)Integrated (8k) L2 table with auto learning; (7)Integrated (2k) L3 table; (8)Integrated (256 KB) data packet memory; (9)64- or 128-bit-wide SDRAM support; (10)Spanning Tree support per VLAN; (11)DiffServ compliant; (12)Stacking architecture compatible with StrataSwitch ITM; (13)IEEE 802.1Q.D support; (14)Fast Filter Processor (FFP); (15)Examines up to the 80th byte of a packet; (16)Supports TOS and DiffServ field modification; (17)Bandwith regulation and monitoring per network flow; (18)Network data flow tracking granular to 1 Mbps.
Diagrams
 |
