Product Summary
The XC5VLX330-2FF1760C is a Platform Flash In-System Programmable Configuration PROM. The XC5VLX330-2FF1760C is available in 1 to 32 Megabit (Mbit) densities; this PROM provides an easy-to-use, cost-effective, and reprogrammable method for storing large Xilinx FPGA configuration bit streams. The XC5VLX330-2FF1760C includes the 3.3V PROM.
Parametrics
XC5VLX330-2FF1760C absolute maximum ratings: (1)VCCINT Internal supply voltage relative to GND:–0.5 to +4.0V; (2)VCCO I/O supply voltage relative to GND:–0.5 to +4.0V; (3)VCCJ JTAG I/O supply voltage relative to GND:–0.5 to +4.0V; (4)VIN Input voltage with respect to GND VCCO＜2.5V:–0.5 to +3.6V; (5)VCCO≥2.5V:–0.5 to +5.5V; (6)VTS Voltage applied to High-Z output VCCO＜2.5V:–0.5 to +3.6V; (7)VCCO≥2.5V:–0.5 to +5.5V; (8)TSTG Storage temperature (ambient):–65℃ to +150℃; (9)TJ Junction temperature: +125℃.
Features
XC5VLX330-2FF1760C features: (1)In-System Programmable PROMs for Configuration of Xilinx FPGAs; (2)Low-Power Advanced CMOS NOR FLASH Process; (3)Endurance of 20,000 Program/Erase Cycles; (4)Operation over Full Industrial Temperature Range (-40℃ to +85℃); (5)IEEE Standard 1149.1/1532 Boundary-Scan (JTAG) Support for Programming, Prototyping, and Testing; (6) JTAG Command Initiation of Standard FPGA Configuration; (7)Cascadable for Storing Longer or Multiple Bitstreams; (8)Dedicated Boundary-Scan (JTAG) I/O Power Supply (VCCJ); (9)I/O Pins Compatible with Voltage Levels Ranging From 1.5V to 3.3V; (10)Design Support Using the Xilinx Alliance ISE and Foundation ISE Series Software Packages.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 XC5VLX330-2FF1760C |
|
IC FPGA VIRTEX-5 330K 1760FBGA |
Data Sheet |
|
|
||||||
