Product Summary
The BUS14A is the silicon NPN power transistor which is used as the converter, inverter and so on.
Parametrics
BUS14A absolute maximum ratings: (1)Collector-base voltage Open emitter: 1000 V; (2)Collector-emitter voltage Open base: 450 V; (3)Emitter-base voltage Open collector: 9 V; (4)Collector current: 30 A; (5)Collector current-Peak: 50 A; (6)Base current: 6 A; (7)Base current-Peak: 10 A; (8)Total power dissipation Tmb=25℃: 250 W; (9)Junction temperature: 200℃; (10)Storage temperature: -65~200 ℃.
Features
BUS14A features: (1)With TO-3 package; (2)High voltage, high speed.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 BUS14A |
Other |
|
Data Sheet |
Negotiable |
|
||||
