Product Summary

The M50195P is a digital ECHO IC fabricated with silicon-gate CMOS technology. The M50195P converts an input analog signal to a digital signal and writes it in a memory IC. After a delay it reads out the digital signal from the memory IC and then converts to an analog signal again. Lower noise and distortion delay signal is obtained by M50195P than BBD. The M50195P is suitable for karaoke, radio cassette tape recorder, viedo-diso player, electronic instrument.

Parametrics

M50195P absolute maximum ratings: (1)VCC, supply voltage: 7V; (2)ICC, circuit current: 70mA; (3)Pd, power dissipation: 1100mW; (4)Topr, operating temperature: -20 to 75℃; (5)Tstg, storage temperature: -40 to 125℃.

Features

M50195P features: (1)low noise: -90dB typ; low distortion: 0.5% typ; (2)3mode delay time: 100, 150, 200msec.

Diagrams

M50195P block diagram
