PIC32MX340F256H

USB 32-Bit Flash Microcontroller, 2.5V, 64-Pin QFN, PIC32MX340F256H

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~2.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~2.00

PartNumber:: PIC32MX340F256H

Brand:: Microchip Technology - Microchip | Pack: DIP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Olin,Ms Stiny's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-05-11

From Other Seller

Part Number:PIC32MX340F256H
US $1.00 - 2.00
ad7716ap

US $1.13 - 1.13 / Piece
(0) Remove
A50L-0001-0175

US $100.00 - 100.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The PIC32MX340F256H is a 64-Pin General Purpose and USB 32-Bit Flash Microcontroller. It is not intended to be a comprehensive reference source.

Parametrics

PIC32MX340F256H absolute maximum ratings: (1)Ambient temperature under bias: -40℃ to +85℃; (2)Storage temperature: -65℃ to +150℃; (3)Voltage on VDD with respect to VSS: -0.3V to +4.0V; (4)Voltage on any combined analog and digital pin and MCLR, with respect to VSS: -0.3V to (VDD + 0.3V); (5)Voltage on any digital only pin with respect to VSS: -0.3V to +5.5V; (6)Voltage on VDDCORE with respect to VSS: -0.3V to 2.0V; (7)Maximum current out of VSS pin(s): 300 mA; (8)Maximum current into VDD pin(s): 300 mA; (9)Maximum output current sunk by any I/O pin: 25 mA; (10)Maximum output current sourced by any I/O pin: 25 mA; (11)Maximum current sunk by all ports: 200 mA; (12)Maximum current sourced by all ports: 200 mA.

Features

PIC32MX340F256H features: (1)Operating Voltage Range of 2.3V to 3.6V; (2)32K to 512K Flash Memory (plus an additional 12KB of Boot Flash); (3)8K to 32K SRAM Memory; (4)Pin-Compatible with Most PIC24/dsPIC Devices; (5)Multiple Power Management Modes; (6)Multiple Interrupt Vectors with Individually Programmable Priority; (7)Fail-Safe Clock Monitor Mode; (8)Configurable Watchdog Timer with On-Chip Low-Power RC Oscillator for Reliable Operation.
