Product Summary

The MS241C3-30S is a 0.4 dual digit numeric display.

Parametrics

MS241C3-30S absolute maximum ratings: (1)Power Dissipation/ Segment: 40mW; (2)Peak Forward Current/ Segment: 60mA; (3)Continuous Forward Current/ Segment: 15mA; (4)Operating temperature range: -25℃ to +85℃; (5)Storage Temperature Range: -25℃ to +85℃.

Features

MS241C3-30S features: (1)High performance Gap, GaAsP Dice; (2)0.4 inch character Height; (3)High Contrast; (4)Wide Viewing Angle; (5)Common Cathode.

Diagrams

MS241C3-30S dimension
