P6KE120A

peak power, transient voltage suppressor, 600 Watts, 1mA, 10V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.10~0.20 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.10~0.20

PartNumber:: P6KE120A

Brand:: Fairchild Semiconductor - Fairchild | Pack: DO | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Olin,Ms Stiny's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-11-28

From Other Seller

Part Number:P6KE120A
US $0.10 - 0.20
YL-G709

US $65.00 - 68.00 / Piece
(0) Remove
IRFP260N

US $1.30 - 4.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The P6KE120A is 600 watt peak power transient voltage suppressor.

Parametrics

P6KE120A absolute maximum ratings: (1)Peak Power Dissipation at T =25℃, T =1ms Minimum: 600 W; (2)Steady State Power Dissipation at TL=75 C Lead Length.375"(9.5mm)PD: 5.0W; (3)Peak Forward Surge Current at 8.3ms Single Half Sine-Wave; (4)superimposed on rated load (JEDEC method) IFSM: 100A; (5)Operating and Storage Temperature Range TJ, TSTG: -55 to +175℃.

Features

P6KE120A features: (1)600 Watts Surge Capability at 1ms; (2)High temperature soldering guaranteed: 260 C / 10 seconds / .375"(9.5mm) lead length, 5lbs.(2.3kg) tension; (3)Typical IR less than 1mA above 10V; (4)Fast response time: Typically less than 1.0ps from 0 volt to BV min.; (5)Low zener impedance; (6)Excellent clamping capability.
