Product Summary
The SAA6721E/V2 is a graphics engine, which converts digital RGB or YUV data into video signals suitable for TFT displays. The SAA6721E/V2 supports SXGA input resolution as well as true colour. Independent horizontal and vertical up and downscaling can display the input data arbitrarily on the connected TFT display. Multi-sync capability allows the applied graphics mode to be detected.
Parametrics
SAA6721E/V2 absolute maximum rating: (1)digital supply voltage,VDDD:-0.5 +4.6 V; (2)PLL supply voltage:-0.5 +4.6 V; (3)voltage at digital inputs and outputs outputs in 3-state:-0.5 +5.5 V; (4)voltage at digital output outputs active:-0.5 VDDD + 0.5 V voltage difference between VSS(PLL) and VSS(D) :100 mV; (5)Tstg storage temperature :-65 to +150 °C; (6)Tamb ambient temperature: 0 to 70 °C; (7)Tamb(bias) operating bias ambient temperature: -10 to +70 °C; (8)electrostatic handling voltage for all pins:-2 to +2 kV.
Features
SAA6721E/V2 features:(1)RGB video input; (2)YUV video input; (3)1.3 Video processing; (4)On screen display; (5)Video output; (6)Memory interfac.
Diagrams
 |
