Product Summary

The TIBPAL20R6-15CNT is a programmable array logic device features high speed and functional equivalency when compared with currently available device. The TIBPAL20R6-15CNT combines the latest Advanced Low-Power Schottky technology with proven titanium-tungsten fuses to provide reliable, high-performance substitutes for conventional TTL logic. Its easy programmability allows for quick design of custom functions and typically results in a more compact circuit board.

Parametrics

TIBPAL20R6-15CNT absolute maximum ratings: (1)Supply voltage, VCC:7 V;(2)Input voltage:5.5 V; (3)Voltage applied to disabled output:5.5 V ; (4)Operating free-air temperature range: 0 °C to 75°C; (5)Storage temperature range: –65 °C to 150°C.

Features

TIBPAL20R6-15CNT features: (1)High-Performance;(2)Reduced ICC of 180 mA Max; (3)Functionally Equivalent, but Faster Than PAL20L8, PAL20R4, PAL20R6, PAL20R8; (4)Power-Up Clear on Registered Devices (All Register Outputs are Set Low, but Voltage Levels at the Output Pins Go High); (5)Preload Capability on Output Registers Simplifies Testing; (6)Package Options Include Both Plastic and Ceramic Chip Carriers in Addition to Plastic and Ceramic DIPs.

Diagrams

TIBPAL20R6-15CNT Pin Configuration

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
TIBPAL20R6-15CNT
TIBPAL20R6-15CNT
Texas Instruments
Programmable Array Logic - Special High-Perf Impact PAL Circuits
Data Sheet
0-1: $2.49
1-25: $2.04
25-100: $1.84
100-250: $1.69
