The M38203M4-125FP is an 8-bit microcomputer based on the 740 family core technology. The M38203M4-125FP has the LCD drive control circuit and the serial I/O as additional functions. The M38203M4-125FP includes variations of internal memory size and packaging. For details, refer to the section on part numbering. For details on availability of microcomputers in the 3820 group, refer to the section on group expansion. The applications of the M38203M4-125FP include Household appliances, consumer electronics, and so on.

Parametrics

M38203M4-125FP absolute maximum ratings: (1)Power source voltage: -0.3V to 7.0V; (2)Input voltage: -0.3V to VCC +0.3V; (3)Input voltage VL1: -0.3V to VL2 V; (4)Input voltage VL2: VL1 to VL3 V; (5)Input voltage VL3: VL2 to VCC +0.3V; (6)Input voltage RESET, XIN: -0.3V to VCC +0.3V; (7)Output voltage P00–P07, P10–P17 at output port: -0.3V to VCC +0.3V; (8)Output voltage P30–P37: -0.3V to VL3+0.3V; (9)Output voltage P20–P27, P41–P47, P50–P57, P60, P61, P70, P71: -0.3V to VCC +0.3V; (10)Output voltage SEG0–SEG15: -0.3V to VL3+0.3V; (11)Output voltage XOUT: -0.3V to VCC +0.3V; (12)Power dissipation: 300mW; (13)Operating temperature: -20℃ to 85℃; (14)Storage temperature: -40℃ to 125℃.
